| ACCESSORY | |
| Fork travel | 100mm - 120mm |
| Head Set Size | φ28.6/42 | 52/φ39.8 |
| Front Wheel Size | 26" |
| Rear Wheel Size | 26" |
| Max Rear Wheel Width | 2.4" |
| Crank Length | ≤175mm |
| Each Inboard Crank to Frame Centerline Clearance | 52mm |
| BB Length | 73mm |
| Seat Post | Ø30.9 |
| OLD | 135mm |
| Chainring max | 32T |
| Brake Disc | 160mm |
| M | L | ||
|---|---|---|---|
| A | Reach | 405mm | 440mm |
| B | Stack | 563mm | 554mm |
| C | Fork Offset | 38mm | 38mm |
| D | Front Center | 645mm | 698mm |
| E | Fork Length | 480mm | 480mm |
| F | Wheel Base | 1024mm | 1078mm |
| G | Rear Center | 380mm | 380mm |
| H | Bottom Bracket Dror | 15mm | 15mm |
| I | Max Seat Post Insertion Depth | 180mm | 180mm |
| J | Top Tube Horizontal Length | 610mm | 641mm |
| K | Head Tube Angle | 70° | 68° |
| L | Head Tube Length | 115mm | 115mm |
| M | Actual Seat Tube Angle | 67.3° | 67.3° |
| N | Effective Seat Tube Angle | 70° | 70° |
| O | Seat Tube Length | 330mm | 330mm |
